Product Introduction:

Traditional Installation Method:

• The insulation structure layer and floor decoration layer have significant thickness.
• Low thermal conductivity efficiency, slow thermal effect, and long heating time.
• Traditional methods use steel mesh, binding straps, and clips to secure piping, which is material-intensive and labor-consuming.
• The insulation structure layer lacks sufficient compressive strength, with ordinary insulation boards bearing only 250 kPa.

Thin-Type Floor Heating Module:

• Simple installation process, saving time, effort, space, and reducing load.
• Features ultra-high compressive strength, high energy efficiency, rapid heating, air insulation, long service life, and flexible installation.

Product Features:

1. Lightweight: Weighs approximately 2.8 kg/m³, reducing building load and saving construction costs.
2. Thin: Ultra-thin (23mm–30mm), preserving ceiling height and increasing living space comfort.
3. High Compressive Strength: Compressive strength ≥ 592 kPa, resistant to cracking and deformation during construction. The material and structural design can also absorb thermal expansion and contraction of concrete.
4. Rapid Heating: Heats up quickly, with energy-efficient systems reaching warmth in 10–20 minutes.
5. Energy-Saving: Independent heating and outdoor metering systems save approximately 30% on energy consumption.
6. High Thermal Efficiency: Scientifically designed structure with interconnected channels for excellent heat transfer and uniform temperature distribution.
7. Thermal & Sound Insulation: Low thermal conductivity of floor modules, combined with an air insulation layer, prevents downward heat loss and reduces inter-floor noise.
8. Long Lifespan: High material stability and weather resistance, made from non-toxic, odorless materials similar to potable water pipes.
9. High Flexibility: Greater freedom in pipe layout, allowing closer spacing based on room-specific heating demands
10. Recyclable Material: Floor heating modules are reusable, supporting sustainable resource utilization.
11. Simple & Efficient Installation: Easy and fast construction, cutting labor time in half compared to traditional methods (eliminating steps like pipe positioning, steel mesh laying, and pipe fixing).

Product Applications:

Industrial, Civil, and Commercial Buildings: Low-temperature radiant floor heating systems. Cooling systems that meet design and usage requirements.

Agriculture, Animal Husbandry, Fisheries, and Forestry: Heating solutions for farming, livestock, aquaculture, and forestry.

Public and Commercial Facilities: Hospitals, hotels, resorts, clubs, libraries, schools, sports stadiums, airports, and other large venues.
